Neo Pro 4K-24V Single Phase Hybrid Inverter
₹85,713.33 Exl GST
Cellcronic Neo Pro Hybrid Inverter is a high-performance energy solution designed for modern homes and businesses. It efficiently combines solar, battery, and grid power to ensure uninterrupted electricity supply. With advanced technology, it delivers maximum power conversion and smart energy management. The inverter supports high solar capacity, making it ideal for sustainable and cost-saving operations. Backed by strong durability and warranty, Neo Pro is a reliable choice for long-term energy independence.
Share
Celebrate Freedom with Power-Packed Discounts!
Starts from 14th August 2025, on Galaxy 6G EU 5Kw
2 in stock
Colorful touch LCD screen
Pure sine wave output.
Compatible with solar Panel and wind turbine as well.
4000W Maximum Load Capacity & 6000W Solar Capacity.
6 time period for battery Charging/ discharging.
Max. Charging/discharging current of 140A
IP54 Protection degree
5 year warranty
Also works with generators
Key Specifications & Features
- AC couple to retrofit existing solar system
- Works as On- grid and Off- Grid mode
- Inverter Designed on 24V DC power and compatible with all Lead- Acid & Lithium Iron Phosphate batteries.
- MPPT Voltage Range 60V-450VDC
- Intelligent IOT based Wi-Fi system,
- Dual Output Inverter for normal and heavy load
- Inverter weight 10.75KG
- 20-25 years design life
- Generator integration
| Model Neo Pro-4K-24V Hybrid Solar Inverter | ||
| Battery Input Data | ||
| Battery Type | Lead–acid or Lithium–ion | |
| Battery Voltage Range (V) | 20~30V | |
| Max. Charging Current (A) | 140A | |
| Max. Discharging Current (A) | 140A | |
| No. of Battery Input | 1 | |
| Charging Strategy for Li–lon Battery | Self-adaption to BMS | |
| PV STRING INPUT DATA | ||
| Max. DC Input Power(W) | 6000W | |
| Max. PV Input Voltage (V) | 500V | |
| Start–up Voltage (V) | 60V | |
| MPPT Voltage Range (V） | 60-450 V | |
| Rated PV Input Voltage(V) | 370V | |
| Max PV Input Current (A） | 25 | |
| No.of MPP Trackers | 1 | |
| No. of Strings Per MPPT Tracker | 1 | |
| AC INPUT/OUTPUT DATA | ||
| Rated AC Input/Output Power (W） | 4000 | |
| Max. AC Input/Output Power (W) | 4000 | |
| Peak Power (off grid) (w) | 2 times of rated power, 10S | |
| Rated AC Input/Output Current (A） | 17.3A | |
| Max AC Input/Output Current (A） | 17.3A | |
| Max. Continuous AC Passthrough(A) | 35A | |
| Power Factor | 0.8 leading to 0.8 lagging | |
| Output Frequency and Voltage | 50/60Hz; 220/230Vac (single phase) | |
| Grid Type | Single Phase | |
| Current Harmonic Distortion | THD<3%(Linear load<1.5%) | |
| EFFICIENCY | ||
| Max. Efficiency | 95.60% | |
| Euro Efficiency | 96.50% | |
| MPPT Efficiency | >99.90% | |
| PROTECTION | ||
| DC Reverse Polarity Protection, | Integrated | |
| AC Output Overcurrent Protection | Integrated | |
| Thermal Protection | Integrated | |
| AC Output Overvoltage Protection | Integrated | |
| AC Output Short Circuit Protection | Integrated | |
| DC Component Monitoring | Integrated | |
| Arc Fault Circuit Interrupter (optional) | Integrated | |
|
Anti-islanding Protection |
Integrated | |
| Insulation Impedance Detection | Integrated | |
| Residual Current Detection | Integrated | |
| DC Switch | Integrated | |
| Surge Protection | TYPE II(DC),TYPE II(AC) | |
| CERTIFICATION AND STANDARDS | ||
| Grid Regulation | IEC 61727,IEC 62116,CEI 0-21,EN 50549，NRS 097,RD 140,UNE 217002,OVE-Richtlinie R25,G98,G99,VDE-AR-N 4105 | |
| Safety EMC/Standard | IEC/EN 61000-6-1/2/3/4, IEC/EN 62109-1, IEC/EN 62109-2 | |
| GENERAL DATA | ||
| Operating Temperature Range(°C) | -10 to +55℃, >45℃ Derating | |
| Cooling | Natural Cooling | |
| Noise(db) | <30 db | |
| Communication with BMS | RS485/RS232/CAN | |
| Weight (kg) | 10.75KG | |
| Cabinet Size (W*H*D mm) | 347mm*445mm*120mm | |
| Protection Degree | IP54 | |
| Installation Style | Wall-mounted | |
| Warranty | 5 Years | |
Frequently Asked
Questions
Installation time varies based on the complexity of your setup, but typically, it takes a professional installer a few hours.
Yes, Cellcronic inverters are compatible with solar panels, allowing you to harness solar energy for your power needs.
Cellcronic offers 2 to 6 years warranty on its inverters, ensuring peace of mind for customers.
Yes, Cellcronic inverters are designed to meet the needs of both residential and commercial applications, offering reliable performance in various settings.
